圆钻琢型光学效果的仿真模拟研究——模型与原理

详细信息

Study on Emulation Model and Principle of Optical Effect of Round Brilliant Cut Diamond

摘要: 钻石切工与其光学效果的关系较复杂,深入研究需要借助计算机三维仿真系统。介绍了钻石三维仿真系统的基本原理与组成。其基本原理为光线跟踪。该系统由光源模型、钻石模型、观察模型及光线跟踪模块组成。定义了两个量化指标:亮度返回值与色光返回值,分别作为成品钻石产生好亮度与好火彩的能力指标。
- 钻石切工 /
- 光学效果 /
- 三维模型 /
- 光线跟踪 /
- 圆形明亮琢型钻石
Abstract: The relation between cut and optical effect of diamond is so complicated that computer 3D emulation model is necessary when it is lucubrated. The basic principle and constituent parts of the diamond 3D emulation system are introduced in the paper. The basic principle is light tracing. The system consists of four parts: light source model, diamond model, observation model and light tracing module. In addition, two numeral indexes are defined: brightness return(BR) and coloured light return(CR), which evaluate the target of good brilliance and good fire on diamond products.
- diamond cut /
- optical effect /
- 3D model /
- light tracing /
- round brilliant cut diamond

[1]	袁心强.钻石分级的原理与方法[M].武汉:中国地质大学出版社,1998.
[2]	Tolkowsky M.Diamond Design:A Study of the Reflection and Refraction of Light in a Diamond[M].London:E & F N Spon,1919.
[3]	Hemphill TS,Reinitz I M,Johnson ML,etc.Modeling the ap-pearance of the round brilliant cut diamond:An analysis of bril-liance[J].Gems & Gemology,1998,34(3):158-183.
[4]	Reinitz I M,Johnson ML,Hemphill TS,etc.Modeling the ap-pearance of the round brilliant cut diamond:An analysis of fire and more about brilliance[J].Gems & Gemology,2001,37(3):174-197.
[5]	Moses TM,Johnson ML,Green B,etc.A foundation for grad-ing the overall cut quality of round brilliant cut diamonds[J].Gems & Gemology,2004,40(3):202-228.
[6]	http://www.gia.edu,2006-02-09.
[7]	Alan Watt.3D计算机图形学[M].包宏译.北京:机械工业出版社,2005.
[8]	叶玉堂,饶建珍,肖峻,等.光学教程[M].北京:清华大学出版社,2005.391-406.
[9]	钟锡华.现代光学基础[M].北京:北京大学出版社,2003.
[10]	David F Rogers.计算机图形学的算法基础(第2版)[M].石教英,彭群生译.北京:机械工业出版社,2002.
[11]	郝允祥,陈遐举,张保洲.光度学[M].北京:北京师范大学出版社,1988.117-126.
[12]	徐海松.颜色信息工程[M].杭州:浙江大学出版社,2005.25-60.
