Tentative Experiment of Synthesizing Single-Crystal Diamond Films by Chemical Vapor Deposition
-
摘要: 采用微波等离子体化学气相沉淀法合成了单晶金刚石膜,探索了化学气相沉淀法(CVD)单晶金刚石膜的生长机理。实验仪器采用石英管式微波等离子体化学气相沉积装置,种晶为3颗IaAB型天然金刚石原石,生长面近平行于(111)和(110)方向,生长温度为800℃,压力约为6 kPa,时间约为8 h。使用宝石显微镜和环境扫描电子显微镜观察分析了CVD单晶金刚石膜的生长表面形貌。结果表明,在生长面上可见明显的生长层,生长晶体无色透明,CVD单晶金刚石膜在生长面上横向外延生长,并形成定向的台阶状表面——“阶梯流”。在相同的条件下,(111)方向上生长的CVD单晶金刚石膜比(110)方向上的更有序。H2浓度的大小对CVD单晶金刚石膜的质量有影响。Abstract: The single-crystal diamond films are grown by the microwave plasma chemical vapor deposition method,as well as the growth mechanism is studied.The experiments are performed in a quartz chamber microwave plasma chemical vapor deposition reactor.Three natural IaAB-type diamond substrates are nearly parallel to(111)-and(110)-oriented.The growth temperature is 800℃,the pressure is about 6 kPa and the growth time is about 8 hours.The surface morphologies of CVD single-crystal diamond films are observed and analysed by microscope and ESEM,which show the lateral growth forming the step-bunched surface——"step-flow".The CVD single-crystal diamond films are colourless and transparent.Under the same condition,CVD single-crystal diamond films grown on(111) direction show more orderly than that on(110).Moreover,the hydrogen concentration could influence the quality of CVD single-crystal diamond films.
-
-
[1] Jes A Smussen, D K Reinhard.Diamond Fil ms Handbook[M].New York:Marcel Dekker, 2002.17-26.
[2] Seiichiro Matsumoto, Yoichiro Sato, Mutsukazu Kamo, et al.Vapor deposition of diamond particles from methane[J].Japanese Journal of Applied Physics, 1982, 21(4):L183-L185.
[3] Philip M Martineau, Si mon C Lawson, Andy J Taylor, et al.Identification of synthetic diamond grown using chemical vapor deposition(CVD)[J].Gems & Gemology, 2004, 40(1):2-25.
[4] Chih-shiue Yan, Yogesh K Vohra, Ho-kwang Mao, et al.Very high growth rate chemical vapor deposition of single-crystal diamond[J].Applied Physical Sciences, 2002, 99(20):12 523-12 525.
[5] Wuyi Wang, Thomas Moses, Robert C Linares, et al.Gem-quality synthetic diamonds grown by a chemical vapor deposition(CVD) method[J].Gems & Gemology, 2003, 39(4):268-283.
[6] Norio Tokuda, Hitoshi Umezawa, Sung-Gi Ri, et al.Atomically flat diamond(111) surface formation by homoepitaxiallateral growth[J].Diamond & Related Materials, 2008, 17(7-10):1 051-1 054.
[7] H Miyatake, K Ari ma, O Maida, et al.Further i mprovementin high crystalline quality of homoepitaxial CVDdiamond[J].Diamond & Related Materials, 2007, 16(4-7):679-684.
[8] http://baike.baidu.com/view/1277.html?wtp=tt, 2006-04-06.
[9] 周健, 傅文斌, 袁润章.微波等离子体化学气相沉积金刚石膜[M].北京:中国建材工业出版社, 2002.34-35. [10] Jocelyn Achard, Alexandre Tallaire, Richardo Sussmann, et al. The control of growth parameters in the synthesis of high-quality single crystalline diamond by CVD[J].Journal of Crystal Growth, 2005, 284(3-4):396-405.
