Surface Microtopography Evolution Characteristics of Freshwater Cultured Pearls in Ezhou, Hubei Province by Inserting Technology
-
摘要: 为了解淡水珍珠的成珠过程, 采用环境扫描电子显微镜对开膜法养殖异形淡水珍珠样品的表面微形貌特征进行了观察。结果显示, 在异形淡水珍珠样品珍珠层中, 成层排列的文石板块形状各异, 具有多层和有序的特点; 在珍珠层的生长初期, 形成于成核小片上的有机质为三角帆蚌外套膜细胞所分泌, 其为后期矿物提供进一步沉淀的局限空间和成核作用的基底, 具有确定矿物成核大小、空间排列、结晶取向和离子堆积是否出现同质多象的功能。同时, 珍珠样品表面出现了与在海水珍珠和以淡水池蝶蚌为母贝的淡水珍珠中类似的螺旋生长纹, 这可能是其在生长过程中受有机质的调控作用, 使文石晶体在不同部位上的堆积具有差异性, 也使文石晶体在特定面网方向上生长, 控制了其成核结晶取向和堆叠方式, 导致其螺旋堆积, 形成类似螺旋纹的生长外观。Abstract: In order to investigate the formation process of freshwater cultured pearls, the surface microtopography characteristics of abnormal-shape freshwater cultured pearls by inserting technology are observed by using the environmental scanning electron microscope(ESEM).The results show that the shapes of aragonite templates with layer arrangement in the nacreous layer of abnormal-shape freshwater cultured pearl samples are various, multilayered and orderly.At the initial stage of the nacreous layer growth, the mantle cells of Hyriopsis cumingii secrete the protein on surface of the nucleation pieces, which provides the matrix and limited space for the minerals in advanced stage, and plays a vital role in mineral nucleation, space arrangement and crystallization orientation.The protein also functions as determining whether there would be homogenous mineral in ion accumulation.A spiral structure, similar to that of seawater pearls or Hyriopsis schlegeli cultured pearls, appears on the surface of the freshwater cultured pearl samples, which might be affected by the regulatory functions of the protein in the growth process.As a result, the aragonite accumulation in different locations is variable, the aragonite crystals grow in the specific lattice direction, and their crystallization orientation and nucleation pattern are controlled, leading to their spiral accumulation and spiral appearance.
-
Keywords:
- abnormal-shape pearl /
- surface microtopography /
- ESEM /
- evolution
-
-
[1] 罗琴凤,亓利剑,尹作为,等.池蝶蚌贝壳及其珍珠的微结构表征[J].宝石和宝石学杂志, 2008, 10(2):17-20. [2] 黄艺兰,亓利剑.珍珠层螺旋生长结构及其生长机制[J].宝石和宝石学杂志, 2005, 7(3):14-19. [3] 黄艺兰,亓利剑.有机质调控下企鹅贝及其附壳珍珠的珍珠层螺旋生长成核[J].宝石和宝石学杂志, 2006, 8(2):20-24. [4] 黄艺兰,亓利剑,李朝阳.企鹅贝附壳珍珠表层螺旋生长结构的原子力显微镜研究[J].宝石和宝石学杂志, 2006, 8(4):1-5. [5] 张刚生,谢先德.贝壳珍珠层微结构及成因理论[J].矿物岩石, 2000, 20(1):11-16. [6] 杨明星,黄凤鸣,周颖.湖北鄂州淡水养殖珍珠的"勒腰"特征及成因[J].宝石和宝石学杂志, 2003, 5(2):11-15. [7] 欧阳健明.生物矿化的基质调控及其仿生应用[M].北京:化学工业出版社, 2006. [8] 张妮.珍珠表面微形貌的AFM和SEM研究[J].岩石矿物学杂志, 2004, 23(4):370-374. [9] 罗程.CaCO3晶体的体外模拟生长过程及机理研究[D].杭州:浙江大学, 2007. [10] 张恩,彭明生,梁超伦,等.珍珠显微结构及纳米矿物的电镜分析[J].矿物学报, 2008, 28(2):112-116. [11] Yao N, Epstein A K, Liu W W, et al.Organic-inorganic interfaces and spiral growth in nacre[J].Journal of The Royal Society Interface, 2009, 6(33):367-376.
[12] Weiner S, Traub W.Macromolecules in mollusc shells and their function in biominerallization[J].Phil Trans R SocLond B, 1984,(304):425-434.
[13] Weiner S, Hood L.Soluble protein of the organic matrix of mollusk shells:A potential template for shell formation[J].Science, 1975, 190(4 218):987-989.
[14] Fairland F A, Edly Destine, Christopher B P, et al.The N-and C-terminal regions of the pearl-associated EF hand protein, PFMG1, promote the formation of the aragonite polymorph in vitro[J].Crystal Growth and Design, 2010, 10(10):4 211-4 216.
