Characteristics of HTHP-Treated Diamonds from Russia
-
摘要: 采用显微观察、红外光谱、可见吸收光谱和低温光致发光谱等分析方法,对9颗俄罗斯高温高压处理钻石样品进行了研究。结果表明,该类钻石样品的内部多见石墨化现象,尤以彩色钻石样品更明显;金黄色、紫红色、黄绿色样品为ⅠaAB型,浅黄色样品为ⅠaB型,近无色样品为Ⅱa型;样品的可见吸收光谱因颜色不同而差异显著,其中金黄色样品可见475 nm处的吸收宽带,紫红色样品可见638,614,595 nm处的吸收峰,黄绿色和浅黄色样品可见415,475,503 nm处的吸收峰,近无色样品则为较光滑的平直曲线。此外,该类样品在低温光致发光谱中可见575 nm与637 nm处强发光峰。这些特征为探讨该类钻石的晶格缺陷与呈色机理提供了一定的科学依据。Abstract: In the paper, the nine HTHP-treated diamond samples from Russia are test by using the micro-examination, FTIR, visible absorption spectrum, low-temperature photoluminescence spectrum and some other methods.The results show that the diamond samples reveal the obvious graphitization, especially the fancy colour diamond samples.The golden yellow, purplish-red, yellowish-green samples are Ⅰ aAB-type;light yellow sample is Ⅰ aB-type and the near colourless samples are Ⅱ a-type.The visible absorption spectra of the samples are very different by the colours.The golden yellow sample reveals the wide absorption band at 475 nm;purplish-red samples reveal the absorption peaks at 638, 614, 595 nm;the yellowish-green samples reveal the absorption peaks at 415, 503 nm and the absorption band at 475 nm;the near colourless samples in the visible region are almost smooth.Besides, the strong luminescent peaks of the samples at 575 nm and 637 nm are observed in the low-temperature(77 K) PL spectra.These characteristics above could provide the foundations for the study on the defects in the crystal lattice and the colouring mechanism of the HTHP-treated diamond.
-
![]()
图 1 树脂化石化学指纹图谱分析流程: (a)样品采集; (b)仪器分析和生物信息学分析Figure 1. Graphic illustration of the workflow to aquire chemical fingerprints of fossil resins, including sample collection(a), and instrument analysis and bioinformatics analysis(b)![]()
图 2 4类琥珀次生代谢物化学分类(a)和小提琴图对比四组次生代谢物(b)Figure 2. Chemical composition classification of the secondary metabolites expressed across the four resin plant (a), and violin plots of the secondary metabolites among four comparative groups (b)![]()
图 3 次级代谢产物相对含量的正交偏最小二乘回归及判别分析(a, b, d, e中红点为化学分类标志物), 箱线图显示南洋杉科和柏科树脂(c)以及豆科树脂(f)化学分类标记的相对含量对比Figure 3. Orthogonal partial least-squares regression and discriminant analysis of the relative contents of secondary metabolites (a and d); S-plot where points with different colors represent the chemotaxonomic markers, the farther away points the center, the higher contribution of the markers to the separation of the groups (b and e); Boxplots showing relative content levels of chemotaxonomic markers in group Araucariacae and Pinaceae resins and group Hymenaea resins (c and f) -
[1] 张蓓莉.系统宝石学(第二版)[M].北京:地质出版社,2006.619-620. [2] Thomas M Moses,James E Shigley,Shane F McClure E A.Observations on GE-processed diamonds:a photographic re-cord[J].Gems&Gemology,1999,8(2):14-22.
[3] 李桂林,陈美华,颜慰萱,等.高温高压处理钻石的谱学特征综述[J].宝石和宝石学杂志,2008,10(1):29-32. [4] 苑执中,彭明生,蒙宇飞.高温高压处理改色的黄绿色金刚石[J].宝石和宝石学杂志,2000,2(2):29-30. [5] F De Weerdt,J Van Royen.高温高压处理的诺瓦钻石的研究[J].宝石和宝石学杂志,2001,3(1):31-34. [6] Wuyi Wang,Christopher P Smith,Matthew S Hall,et al.Treated-color pink-to-red diamonds from Lucent DiamondsInc[J].Gems&Gemology,2005,41(1):6-19.
[7] 陆宇刚,买潇,覃勇,等.高温高压处理褐色钻石的实验探索[J].宝石和宝石学杂志,2007,9(11):27-30. [8] Johnson P,Breeding C M.Treated fancy red diamond[EB/OL].News from Research,http://www.gia.edu/research-resources/news-from-research/,2009-06.
[9] 谢先德.中国宝玉石矿物物理学[M].广州:广东科技出版社,1999.42-43. [10] James E Shigley.High-pressure-high-temperature treat-ment of gem diamonds[J].Elements,2005,1(3):101-104.
[11] Christopher P Smith,George Bosshart,Johann Ponahlo EA.GE POLdiamonds:before and after[J].Gems&Gem-ology,2000,36(3):192-215.
